Multi use split butterfly valve (AVAX AF MUT)

AVAX-AF stainless steel Containment Split Butterfly Valve with active flange and suction port.

Share

Operation conditions
– Operating temperature -20°C to +50 °C
– Resistance temperature (material) -20°C to +80 °C

Application
– Containment level: OEL of <1,0 μg/m³ (according to ISPE previously SMEPAC)

Standard assemblies
– Containment interface Tri Clamp BS 4825-3
– Manual execution fixed hand lever on the flange with stop for adjusting the valve disc
– Suction port Tri Clamp DN25 acc. to DIN 32676-A

Dimensions
– Nominal diameter DN100
– Component assembly 199 mm x 121,3 mm (diameter x height)
– Hand lever 292,5 mm
– Weight 20 kg

Surface details
– Surface roughness Ra ≤ 0,8 µm (Product contact space)
– Ra ≤ 1,6 µm (Non product contact space)

Material
– Stainless steel production parts 1.4404 / 316L (Product contact) 1.4301 / 304 (Non product contact parts)
– Sealings FPM or PTFE; FEP O-RING (Product contact parts)
– Bearings PEEK (Non product contact parts)

Certification / Datasheets
– Material specification
– FDA conformity (Product contact parts)

Compatibility / Accessories
– Compatible systems AVAX plastic, ACUBE, ACUBE-PRO, AVAX stainless steel, Adjustable frame for ACUBE
– Accessories operation AVAX Locking Tool, Lid, AVAX stainless steel wash adapter, Handle

More information on manufacturer`s website:
