Container and drum agitators

The container and drum agitators can agitate media with up to 30,000 mPas in IBC containers and standard 200-litre drums before further processing or process them efficiently and sustainably in the container itself.

Share

Bestseller
VISCO JET® VJ350 container agitators are ideally suited for applications with IBCs, both in the standard version and with individual adaptations:
– Various drive powers from 0.55 – 3.0 kW for media with a viscosity of up to 30,000 mPas;
– Individual speed adjustment using a built-on frequency converter and potentiometer;
– Stainless steel cross beam with forklift pockets for quick and easy mounting on the lattice structure of the IBC;
– VISCO JET® Tornado impeller for openings from DN150;
– High-quality stainless steel agitator for easy and fast cleaning and a long service life;
– Agitator design with individual additional components such as a feed hopper or switch set including agitating time adjustment and much more;
– Design of the agitator for the ATEX area available as an option.

The expert for small openings
Quick and uncomplicated – the products can be agitated directly in the barrel with the VISCO JET® VJ370 agitators, thus preventing a loss of quality due to residues or sedimentation in the barrel:
– Drive power of 0.37 kW for a customized and sustainable solution for the agitating task of up to 1,000 mPas;
– Simple and safe installation of the agitator on the drum rim by means of an angled cross beam;
– Foldable VISCO JET® MISTRAL impeller for optimum agitating results;
– High-quality, durable and stainless steel agitator – quick and easy to clean;
– Low wear of the agitator components due to low speeds;
– Design of the agitator for the ATEX area available as an option.

The specialist for open drums
Quick and uncomplicated – the products can be stirred directly in the barrel with the VISCO JET® VJ380 agitators, thus preventing a loss of quality due to residual quantities or sedimentation in the barrel:
– Drive power 0.37 kW offers an individual and sustainable solution for the customer’s stirring task up to a viscosity of 5,000 mPas;
– Simple and safe assembly of the agitator including rotation lock on the drum rim;
– High-quality, durable and stainless steel agitator – quick and easy to clean;
– VISCO JET® CLASSIC for optimum stirring results with consistent product quality over the long term;
– Low wear of the agitator components due to low speeds;
– Design of the agitator for the ATEX area available as an option.

The specialist for mobile tanks
During the development and engineering of VISCO JET® VJ520 agitators, we focus on process optimisation and safety, energy efficiency, sustainability and ease of maintenance in order to offer efficient solutions for the further development of processes and products in all industries:
– Specially developed for stainless steel transport containers with lids;
– Customised agitator solutions from a single source with individual drive power from 0,55 kW;
– Compact design with lifting bracket for easy installation and commissioning;
– Can be combined with all VISCO JET® impeller solutions for optimum agitating results with consistent quality over the long term;
– Low wear of the agitator components due to low speeds;
– Design of the agitator for the ATEX area available as an option.

More information on manufacturer`s website:
